| Processor |
|---|
| Processor generation | 12th gen Intel® Core™ i5 |
| Bus type | DMI4 |
| Processor cache | 18 MB |
| Processor model | i5-12500T |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 4.4 GHz |
| Processor cores | 6 |
| Processor family | Intel® Core™ i5 |
| Memory |
|---|
| Memory layout (slots x size) | 1 x 16 GB |
| Internal memory | 16 GB |
| Maximum internal memory | 64 GB |
| Memory slots | 2x SO-DIMM |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Storage |
|---|
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Optical drive type | No |
| SSD interface | NVMe, PCI Express |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Total storage capacity | 256 GB |
| SSD form factor | M.2 |
| Total SSDs capacity | 256 GB |
| SSD performance class | 35 |
| NVMe | Yes |
| Graphics |
|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel UHD Graphics 770 |
| Optical drive |
|---|
| Optical drive type | No |
| Network |
|---|
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN data rates | 10,1000,100 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| WLAN controller model | MediaTek MT7921 |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Antenna type | 2x2 |
| WLAN controller manufacturer | MediaTek |
| Ports & interfaces |
|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| HDMI version | 1.4b |
| USB 2.0 ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Technical details |
|---|
| Intel 64 | Yes |
| Cable lock slot type | Kensington |
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Black |
| Chassis type | mini PC |
| Audio system | High Definition Audio |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Motherboard chipset | Intel B660 |
| Design |
|---|
| Cable lock slot type | Kensington |
| Product colour | Black |
| Chassis type | mini PC |
| Placement supported | Horizontal/Vertical |
| Cable lock slot | Yes |
| Performance |
|---|
| Embedded options available | No |
| Audio chip | Realtek ALC3246-CG |
| Product type | Mini PC |
| Trusted Platform Module (TPM) | Yes |
| Audio system | High Definition Audio |
| Motherboard chipset | Intel B660 |
| Software |
|---|
| Operating system language | German, Dutch, English, French, Italian |
| Operating system architecture | 64-bit |
| Trial software | McAfee® Small Business Security 30-day trial,No Microsoft Office License Included 30 day |
| Operating system installed | Windows 10 Pro |
| Windows 11 free upgrade | Yes |
| Processor special features |
|---|
| Embedded options available | No |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Idle States | Yes |
| Execute Disable Bit | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel 64 | Yes |
| Power |
|---|
| Power supply input frequency | 50 - 60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 65 W |
| Operational conditions |
|---|
| Operating altitude | 0 - 3048 m |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 35 °C |
| Non-operating altitude | 0 - 10668 m |
| Operating vibration | 0.26 G |
| Non-operating vibration | 1.37 G |
| Non-operating shock | 105 G |
| Weight & dimensions |
|---|
| Width | 36 mm |
| Depth | 178 mm |
| Height | 182 mm |
| Weight | 1.33 kg |
| Packaging content |
|---|
| Cables included | AC |
| Display included | No |
| Keyboard included on selected markets only | Yes |
| Input device model | KB216+MS116 |
| Other features |
|---|
| Trusted Platform Module (TPM) | Yes |
| On-board graphics card | Yes |
| Processor manufacturer | Intel |
