| Specification |
| Ports & interfaces |
|---|
| Internal | Yes | | Output interface | Serial | | Serial interface type | RS-232 | | Serial ports quantity | 2 | | Host interface | PCI/PCI-X | | Technical details |
|---|
| Chipset | ASIX - MCS9865 | | FIFO (First In, First Out) | 256 B | | Sustainability certificates | RoHS | | Performance |
|---|
| Stop bits | 1, 1.5, 2 | | Baud rate | 115.2 Kbit/s | | Chipset | ASIX - MCS9865 | | FIFO (First In, First Out) | 256 B | | Flow control support | Yes | | Product colour | Black | | Harmonized System (HS) code | 84733020 | | Colour |
|---|
| Product colour | Black | | Design |
|---|
| Internal | Yes | | Product colour | Black | | Features |
|---|
| Stop bits | 1, 1.5, 2 | | Baud rate | 115.2 Kbit/s | | Chipset | ASIX - MCS9865 | | FIFO (First In, First Out) | 256 B | | Flow control support | Yes | | Parity bit | Even, Mark, N, Odd, Space | | Flow Control type | N, RTS/CTS, XON/XOFF | | Harmonized System (HS) code | 84733020 | | Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 70 °C | | Storage temperature (T-T) | -20 - 85 °C | | Operating relative humidity (H-H) | 10 - 90% | | System requirements |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 | | Linux operating systems supported | Yes | | Server operating systems supported | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 | | Weight & dimensions |
|---|
| Width | 21.6 mm | | Depth | 134 mm | | Height | 120 mm | | Weight | 141 g | | Package width | 142 mm | | Package depth | 170 mm | | Package height | 30 mm | | Package weight | 170 g | | Packaging data |
|---|
| Mounting brackets included | Yes | | Package width | 142 mm | | Package depth | 170 mm | | Package height | 30 mm | | Package weight | 170 g | | Quick installation guide | Yes | | Logistics data |
|---|
| Products per master (outer) case | 40 pc(s) | | Master (outer) case width | 360 mm | | Master (outer) case length | 385 mm | | Master (outer) case height | 340 mm | | Packaging content |
|---|
| Mounting brackets included | Yes | | Quick installation guide | Yes | | Other features |
|---|
| Chipset | ASIX - MCS9865 | | Flow control support | Yes |
|
